Tankers






  Name Of Vessel
:
MT PETRO MARINE 1
  Port Of Registry
:
JAKARTA
  Nationality
:
INDONESIA
  Official Number
:
NA
  Type Of Ship
:
Oil Tanker Double Bottom / Single Hull
  Call Signal
:
P M G E
  Classification
:
ZC
  Gross Tonnage
:
2,179 MT
  Net Tonnage
:
1,220 MT
  Dead Tonnage
:
3,500 MT
  Length Over All (LOA)
:
86,30 MT
  Length Between Perpendicular (LBP)
:
79,60 MT
  Breadth
:
13,50 MT
  Max Height From Keel
:
26,88 MT
  Deep
:
6,50 MT
  Summer Draft
:
5,70 MT
  IMO Number
:
NA
  Builder
:
CHILRING SHIPYARD, CHINA
  Year Build
:
JAN 05,2004
  Number Of Manifold For Each Side
:
EACH 2 MANIFOLD (P&S)
  Manifold Type
:
DN 200
  Number Of Tanks Capacity Incl Slop Tank (98 PCT)
:
10 TANKS/ 4,344.73 M3
  Type Of Coating
:
INSULATED PAINT
  SWL Derrick / Crane
:
NA
  Speed Service
:
10 KN


  Name Of Vessel
:
MT PETRO MARINE 2
  Port Of Registry
:
JAKARTA
  Nationality
:
INDONESIA
  Official Number
:
NA
  Type Of Ship
:
Oil Tanker Double Bottom / Single Hull
  Call Signal
:
P M G F
  Classification
:
ZC
  Gross Tonnage
:
2,179 MT
  Net Tonnage
:
1,220 MT
  Dead Tonnage
:
3,500 MT
  Length Over All (LOA)
:
86,30 MT
  Length Between Perpendicular (LBP)
:
79,60 MT
  Breadth
:
13,50 MT
  Max Height From Keel
:
26,88 MT
  Deep
:
6,50 MT
  Summer Draft
:
5,70 MT
  IMO Number
:
NA
  Builder
:
YUEQING QI LI GANG SHIPBUILD,
LIMITED COMPANY
  Year Build
:
DEC 04, 2003
  Number Of Manifold For Each Side
:
EACH 2 MANIFOLD (P&S)
  Manifold Type
:
DN 200
  Number Of Tanks Capacity Incl Slop Tank (98 PCT)
:
10 TANKS/ 4,344.73 M3
  Type Of Coating
:
INSULATED PAINT
  SWL Derrick / Crane
:
NA
  Speed Service
:
10 KN
